Every year, students in Science, Technology, Engineering and Mathematics (STEM) participate in Eco-Marathon competitions globally. The goal is to engineer the world’s most energy efficient vehicles.

Spectronik has specially developed the Protium Eco-Marathon (PEM) Package – designed to eliminate the complexity of Hydrogen fuel cell system integration and help participants focus solely on breaking efficiency records. PEM is available in 2 variants – 300W (PEM-300) for the Prototype and 450W (PEM-450) for the Urban Concept vehicle categories.

We have utilized the same core materials, product architecture and component reliability as the ones used in our military and aerospace programs to ensure that all vehicles powered by Spectronik fuel cells achieve their utmost potential. Let’s work together towards a highly efficient Hydrogen powered future mobility!
​​​​​​




FEATURES



High Efficiency
Up to 57% electrical efficiency



Integrated Leak Sensor
Increased user safety by early detection of stack leakage



Manual Override
Flexibility to change and optimize settings such as fan speed and purge frequency




Remote Technical Support
Live technical support during system integration phase and race days

High Power Density
1kg weight and 2.5L volume

Plug and play
No tools required for assembly

Hybrid Supercapacitors
For start-up power, peak acceleration and regenerative braking

Long Range Telemetry (Optional)
10km+ radio modem transmission for pit-side crew to monitor and remotely control fuel cell during race



Low Purge Losses
<3% due to intelligent dynamic purge frequency



DC-DC Converter
Buck/boost voltage regulation to match various motor voltages and fixed operation at most optimal point



Remote Control
Ability to turn on/off the fuel cell via PC GUI without accessing hard-to-reach vehicle compartment




IOT Ready
Live monitoring of fuel cell status and logging of data while driving by connecting to a PC

Select:

Specifications


Fuel Cell
Protium-300
Type
PEM
No. of cells
40
Architecture
Open cathode
Coolant
Air cooled
Rated/gross power
300/360W
Rated/gross current
12.5/15A
Voltage output
24-36VDC
Start-up time
<30s
Operating ambient temperature
[0,35]°C
Operating altitude w/o power derating
1500m AGL
System weight
950g
Max dimension
221 x 113 x 87mm
Cell reaction area
21 sq.cm
Fuse
ATOF®-series 20A, 32V fast acting Blade Fuse Part No. 0287020.PXCN
Fuseholder
Littelfuse Part No. 0FHA0002ZXJ

Specifications


Fuel Cell
Protium-450
Type
PEM
No. of cells
60
Architecture
Open cathode
Coolant
Air cooled
Rated/gross power
450/540W
Rated/gross current
12.5/15A
Voltage output
36-54VDC
Start-up time
<30s
Operating ambient temperature
[0,35]°C
Operating altitude w/o power derating
1500m AGL
System weight
1,300g
Max dimension
290 x 113 x 87 mm
Cell reaction area
21 sq.cm
Fuse
ATOF®-series 20A, 32V fast acting Blade Fuse Part No. 0287020.PXCN
Fuseholder
Littelfuse Part No. 0FHA0002ZXJ

Electric Controller


Processor board
FEATHER V1.2 ESD
External power supply requirement
15-60V, 30W max
Weight (including casing)
680g
Output connector
XT-60 female (DC-DC regulated voltage)<br> Harting D sub DA-7W2 (stack unregulated voltage)
Warning & protections
Low voltage, high/low temperature, high/low pressure, low external power supply, stack leakage
Communication
UART (USB cable for PC connectivity provided)
Data acquisition (DAQ) software GUI
PC app
Remote control
Fan speed, manual purge, remote on-off, stasis on-off

Electric Controller


Processor board
FEATHER V1.2 ESD
External power supply requirement
15-60V, 50W max
Weight (including casing)
680g
Output connector
XT-60 female (DC-DC regulated voltage)<br> Harting D sub DA-7W2 (stack unregulated voltage)
Warning & protections
Low voltage, high/low temperature, high/low pressure, low external power supply, stack leakage
Communication
UART (USB cable for PC connectivity provided)
Data acquisition (DAQ) software GUI
PC app
Remote control
Fan speed, manual purge, remote on-off, stasis on-off

What’s in the Box


  • 40-cells (PEM-300) or 60-cells (PEM-450) graphite plate fuel cell stack
  • 24-cells series (450F each) supercapacitors pack with cell balancing IC, protective casing and voltage monitoring LCD
  • Electronic controller with integrated DC-DC converter (Voltage and Current user-adjustable via PC GUI)
  • Heat management system (cooling fans with pwm control)
  • Fuel supply system (Solenoid valves, gas pressure sensors, gas tubing and connector)
  • On-off push button with status LED
  • Power and signal cables
  • Fuse in the fuel cell power output line
  • Uart-to-USB cable for data telemetry
  • Factory Acceptance Tests (FAT) report
  • Storage casing


TESTIMONIAL


Year Team Country Competition Placing Category Efficiency (km/m­3)
2023 KUST Republic of Korea SEM Asia Pacific & The Middle East 1st   PROTOTYPE 373.65
2023 ANTASENA ITS TEAM Indonesia SEM Asia Pacific & The Middle East 3rd   PROTOTYPE 216.23
2023 HYD12OGEN Singapore SEM Asia Pacific & The Middle East 2nd   URBAN CONCEPT 238.26
2024 HAN Hydromotive The Netherlands SEM Europe & Africa 2nd   URBAN CONCEPT 277.00


FREQUENTLY ASKED QUESTIONS


No. Our products are designed to comply with Shell Eco-Marathon rules for the Hydrogen fuel cell Prototype and Urban Concept categories to the best of our knowledge. However, please note that the rules are updated from time to time and the onus will be on participants to check the latest rules and regulations.

As we have no control over how customers use our fuel cells (e.g. the Hydrogen gas purity that is fed into the fuel cell), we do not warrant against power output. Prior to shipment, you will receive photos, videos, and Factory Acceptance Test report proving the full power output of your system.

All other BOP components are fully warrantied for 1 year from the date of delivery, unless there is clear sign of mishandling or abuse. Beyond the 1-year warranty period, troubleshooting is free-of-charge and any paid repairs cover material and manpower costs only with no mark-up.

PEM-300 and PEM-450 are typically in stock. Otherwise, lead time is 4-6 weeks upon Purchase Order confirmation and upfront payment.

A lot of teams ask Spectronik for discount and sponsorship. It is unfair for us to only selectively sponsor some, while it is not sustainable to sponsor everybody. Therefore, for first time customer, we adopt a strictly no discount/sponsorship policy.

However, for repeat customers who consistently use Spectronik’s fuel cell for at least 2 years, we will consider a deeper collaboration on a case-by-case basis, such as our Sponsorship Agreement with HAN Hydromotive.

Beyond a competitive product, Spectronik believe we are the best partner for Shell Eco-Marathon teams due to the following:

  1. Unlimited remote technical support via zoom: our engineers can provide technical support via zoom call to help you throughout the system integration process, answer questions regarding the Hydrogen fuel cell, and give feedback and advice from previous competition experience.

  2. On-site support during competition days: if there are more than 2 teams using Spectronik fuel cell in a Shell Eco-Marathon competition, Spectronik will send a representative to provide on-site assistance, as well as a spare fuel cell system for backup. This gives you a peace of mind that you will be able to complete the race.

  3. Cash reward: US$1,500 (1st place), US$1,000 (2nd place) and US$500 (3rd place) for teams that use Spectronik fuel cell and finish on the podium at Shell Eco-Marathon competition to reward you for your great efforts! (Terms and Conditions apply).

Congratulations! Thank you for proving that Hydrogen mobility is real and happening now! To claim your cash reward, send us some photos of Spectronik fuel cell in your vehicle and write a testimonial on your experience working with us. Please note that we will seek your permission to post this on our official website and social media channels.

PEM-300 and PEM-450 are not open-source systems and are not designed for such modifications. However, advanced users can choose to do so at their own risks. Please note that warranty will be void and Spectronik cannot give any technical advice on the proposed modifications.

Yes, but the technical merit and feasibility will be evaluated on a case-by-case basis. As we do not foresee mass manufacturing of your custom design, your system may cost significantly more than the standard PEM-300 and PEM-450. Please plan your schedule accordingly as any custom fuel cell will need at least 6 months from design, production, assembly and testing.
